Seeed Studio BeagleBone® Green will boot Linux from the on-board 2GB or 4GB eMMC. This will both power the board and provide a development interface. Use the provided micro USB cable to plug your Seeed Studio BeagleBone® Green into your computer.

Plug in your Seeed Studio BeagleBone® Green via USB The steps are familiar for the other operate systems.

Beagle driver serial#

Serial Debug - Connect to UART0, PIN1~PIN6: GND, NC, NC, RX, TX, NC, note that pin1 is near to the USB.Įach digital I/O pin has 8 different modes that can be selected, including GPIO.

Uart Grove Interface - Connected to UART2.

I2C Grove Interface - Connected to I2C2.

Use as a normal button after boot, connect to GPIO_72.

When there's a SD card insert, the system will boot from SD card first, if you want to boot from eMMC, press this button and then power on.

D5 is configured at boot to light during eMMC accesses.D4 is configured at boot to light during CPU activity.D3 is configured at boot to light during microSD card accesses.D2 is configured at boot to blink in a heartbeat pattern.DC Power and USB Client - Power the board and act as client.Seeed Studio BeagleBone® Green Acrylic Case Here are some funny projects for your reference. NEON floating-point & 3D graphics accelerator Cloud9 IDE on Node.js w/ BoneScript library.Fully Compatible with BeagleBone® Black.The on-board HDMI is removed to make room for these Grove connectors.īoot Linux in under 10 seconds and get started on development in less than 5 minutes with just a single USB cable. The Seeed Studio BeagleBone® Green includes two Grove connectors, making it easier to connect to the large family of Grove sensors. It is based on the classical open-source hardware design of BeagleBone® Black and developed into this differentiated version. It is a joint effort by and Seeed Studio. Seeed Studio BeagleBone® Green is a low cost, open-source, community supported development platform for developers and hobbyists.
